Multi Volt 2V To 12v Dc Regulated Power Supply For Tungsten Lamp

Multi Volt 2V To 12v Dc Regulated Power Supply For Tungsten Lamp

Multi Volt 2V To 12v Dc Regulated Power Supply For Tungsten Lamp
Multi Volt 2V To 12v Dc Regulated Power Supply For Tungsten Lamp
Multi Volt 2V To 12v Dc Regulated Power Supply For Tungsten Lamp
Product Details:
Place of Origin: China
Brand Name: OWPS
Certification: CE,UL
Model Number: OWPS-0216DT
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Carton
Delivery Time: 5-15days
Payment Terms: TT,LC,Paypal
Supply Ability: 300sets/day
Contact Now
Detailed Product Description
Lamp Voltage: 10V Input Voltage: AC 85V-285V
Turn Off Signal: 3 ~ 12V / 1 MA Maximum Input Current: 0.8 A
Tungsten Lamp: 2V-12V
High Light:

multiple output 12 volt dc power supply

,

multi volt dc power supply

,

12v dc regulated power supply

DEUTERIUM LAMP+TUNGSTEN LAMP INTEGRATED POWER SUPPLY used in UV spectra chromatography , atomic absorption,

DEUTERIUM LAMP+TUNGSTEN LAMP INTEGRATED POWER SUPPLY



Compared to the traditional linear power supplies this deuterium lamp switching power supply abolishes cumbersome transformers, it has set filament preheat, high voltage trigger and constant current control are just a number of features the D2 power supply to ensure the stability of UV spectra. A small compact size, light weight and one of the biggest advantage is applicable to international mains input Voltage in the 85 -265V AC, no switching required! The power supply also has control port allowing external control signals (such as CPU or manual) which can easily turn on or off the deuterium lamp.





OWPS-0216DT





USER MANUAL





Part1....................................................................................................................Introduction

Part 2........................................................................................... Environmental Requirement

Part 3...................................................................................................... Technical parameters

Part 4............................................................................................................................ Wiring

Part 5............................................................................................................ Light up the lamp

Part 6................................................................................................... Installation and Cooling

Part 7.............................................................................................. Transportation and storage

Part 8.............................................................................................Maintenance and attention



OWPS 0216DT series Deuterium lamp power supply was developed by OWO team in 2014,and its perfect replacement for expensive original models, the product has CE proved and 18 months warranty.

OWO now offer Deuterium lamp power supply that is commonly used in UV spectra chromatography , atomic absorption, UV-Visible spectrophotometer ,other spectroscopic equipments and also can be connect with tungsten lamp.

Compared to the traditional linear power supplies this deuterium lamp switching power supply abolishes cumbersome transformers, it has set filament preheat, high voltage trigger and constant current control are just a number of features the deuterium power supply to ensure the stability of UV spectra. A small compact size, light weight and one of the biggest advantage is applicable to international mains input Voltage in the 85-265V AC, no switching required! The power supply also has control port allowing external control signals (such as CPU or manual) which can easily turn on or off the deuterium lamp.

OWPS-0216DT series deuterium power supply has professional anti-electromagnetic interference design, the electromagnetic interference reach to grade A.

OWPS-0216DT series power supply support deuterium lamp and tungsten lamp use, the voltage offering for the tungsten lamp can be customized to 6V,12V,24V, power range:5W-30W.







Part 2: Environmental Requirement

1. operating environment:

Temp.: 0-40℃

RH: 40℃(20-90)% RH

Pressure: 86-106 KPa

2. storage environment:

Temp.: -40-70℃

RH: 50℃ 90% RH

Pressure: 86-106 KPa





Part 3:Technical parameters



OWPS-0216DT
Voltage input: AC 85 ~ 265V
Maximum input current:0.8A

Filament voltage:

Preheat:DC 2.5V or 10V

Working:0V or 6-7V

Tungsten lamp voltage:

2V-12V

Current:2A

Maximum anode voltage:

Preheat:DC 125V

Working:DC60-80V

Turn off signal:

3-12V/10mA

Anode current:300mA Note: please add effective isolation between deuterium lamp and tungsten lamp

Constant flow accuracy: 0.05‰(after starting 1h)

Minimum trigger voltage:DC 550V
Withstanding Voltage:AC 1500V / 1min
Turn off signal: 3 ~ 12V / 10mA
Dimension:130 * 99 * 40 mm
Net Weight:0.4kg
