55W BLDC water pump, 24VDC input and can be PWM control, speed pulse signal feedback.
  • name
  • name
  • name

55W BLDC water pump, 24VDC input and can be PWM control, speed pulse signal feedback.

MOQ: 5
Price: Negotiable
Standard Packaging: PE bag+carton
Delivery Period: 5-10days
Supply Capacity: 1000pcs/month
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Bextreme shell
Model Number
DKB60TSB
Working Voltage:
16-30VDC(24VDC）
Power:
55W
Motor:
Brushless DC Motor
Speed Regulation:
PWM
Nozzle Diameter:
1/2 Inch
Flow Range:
0-22L/min
Range Of Lift:
0-11M
Noise:
≤40dB
High Light:

brushless dc fan driver

,

bldc ceiling fan driver

,

Brushless BLDC Fan Driver

Product Description



DKB60TSB Series Industrial Brushless DC Water Pump

Boosting/circulation /Low-noise/centrifugal pump



55W BLDC water pump, 24VDC input and can be PWM control, speed pulse signal feedback. 0



■ Applications
1:Solar heating water circulation
2:Water Purification Equipments
3:Drinking water machines
4:Automatic water dispenser
5:Water cooling equipment
6:Engine cooling
7:Heating equipment cooling
8:Cooling Towers
9:Irrigation Landscape
10: Pipeline boosting



■ Features
◆Centrifugal pump
◆Magnetic force transmission (shield pump structure)
◆High efficiency brushless DC motor, low power consumption, high efficiency,
long service life.
◆With wide range operating temperature
◆PWM signal speed controlling
◆With constant flow controlling

◆Reverse polarity protection (optional)
◆Dry running protection (optional)
◆Over Voltage, over current protection
◆Overload, over temperature protection

■ Technical description (parts in contact with the liquid)
Pump head housing: PK+GF
Impeller: PPE+GF
Shield cavity: PK+GF
Shaft sleeve: Carbon resin composite materials/ ceramic sleeve
Shaft: ceramics axis/stainless steel shaft
Seal ring: EPDM

■ Driving device (Including motor)
Driving electromagnet: Plastic magnetic molding
Screws and nuts: SUS 304 stainless steel
Driving Motor : brushless motor
Motor wire frame: PPA+GF (black)
Pump housing: PPS+GF(UV resistance)
Waterproof based on IP65 rating (en60529)
Wiring:3 leads / Waterproof connector is optional
Nozzle diameter:20.5mm (inner diameter:14.5mm)
■ Model Specifications

DKB60TSB-24G 24 V

■ Mounting instruction

DKB60TSB series pumps are centrifugal pumps which require pre-filled,
The pump installed in the lowest position of the system to ensure that the
impeller is always immersed in the liquid, or pre-filled the pump before
power on .
1: Pump should not be dry-running, even though it can dry-running for 30
seconds (after 30 seconds dry-running, it will automatically stop), Dry
running will makes noise, also increasing abrasion to the shaft and shaft
sleeve.
2:Use the recommended diameter threaded pipe connecting the pump
inlet, if you use a smaller diameter hose pump inlet, Due to the negative
pressure in the pump, the outside air easier enter to the pump through
the pipeline, it will make the pump performance degradation, and also
the air bubbles make damage to the pump.
3: As viewed from the pump inlet direction, the impeller rotates clockwise
(see the arrow on the outlet port).
4: The pump can be installed vertically or horizontally mounted (see
figure 1 ) When installed vertically, the outlet port should be upward .
5:In order to avoid the dry- running (air get stuck in impeller),the water
pump outlet port should be vertical or in the upper of the impeller. (see
figure 1 )
6: The connected pipe should be vertically mounted (or no elbow in
20cm )to make the air discharged easily, the outlet pipe should not be
used less than 90 degrees Elbow (see figure 2).
7: Can't use the seawater or other heavy pollution with big grain impurity
liquid as the liquid medium .
55W BLDC water pump, 24VDC input and can be PWM control, speed pulse signal feedback. 1
55W BLDC water pump, 24VDC input and can be PWM control, speed pulse signal feedback. 2
■ Temperature parameter
Medium liquid temperature: -25℃ to +105℃ (-13°F to + 221°F)
Working ambient temperature: -10℃ to +100℃ (14°F to +212°F)
Storage temperature: -40℃ to +70℃ (-40°F to +158°F)
(up to 100 ℃, but it will shorten the service life)

■ System pressure
-0.2 to 2.5 bar ( 100℃ (212°F).
The service life is more than 20,000 hours based on the rated voltage
and 36℃(86°F) ambient temperature.

■ Voltage range
Rated 24V water pump, workable range 16V - 30V
Although the motor can be used in a wide range of voltage and
temperature, but excessive or too low voltage and temperature will affect
the service life of the motor, the pump can not be exposed to thermal
radiation ambient.
Medium liquid: pure water, liquid mixture (Water with below 60% glycol)

■ Electrical parameter
Specification:
No. category specification
1 Rated voltage 24V
2 Workable voltage 16V-30V
3 Rated power 5-55W
3 Flow range 0-22L/minuts
4 Range of lift 0-11M
5 Noise ≤40dB
6 Service life 20000H
7 Operating mode continuous working
8 Diameter of inlet 20.5mm( inside diameter:14.5mm)
9 Diameter of outlet 20.5mm( inside diameter:14.5mm)

■ Description of Wiring
Standard length of the wire: 40 CM (DO NOT DRAG THE WIRE)
55W BLDC water pump, 24VDC input and can be PWM control, speed pulse signal feedback. 3
■ Description of PWM

Three ways for speed regulation
1: 0-5V analog voltage
2:PWM duty cycle ratio 0%-100% (chart below)
3: Input PWM frequency (1K-10K Hz)

55W BLDC water pump, 24VDC input and can be PWM control, speed pulse signal feedback. 4

All datas are customizable for customer
■Customization service:
1:The pump parts customizable according to customer specific
requirements
2:Pumps’ performance parameters customizable according to
customer's requirements
3:Optional accessories of the pump customizable according to
customer's requirements
4:Special circuit program customizable according to customer
requirements
5:The outer housing can be customizable according to customer's
requirements

55W BLDC water pump, 24VDC input and can be PWM control, speed pulse signal feedback. 5
