|Place of Origin:||China|
|Minimum Order Quantity:||5 sets|
|Payment Terms:||L/C, T/T,L/C|
|Operate Voltage:||DC 18V-32V||Max Flow::||5000L/H|
|Max Head::||20M||Rated Flow &lift:||2400L/H, H=17M|
5000L/H Automotive Coolant Water Pump,
72VDC Vehicle Coolant Water Pump,
5000L/H Vehicle Coolant Water Pump
Mobile Electric Vehicle Charging System Automotive Coolant Dc Brushless Water Pump
* Essential Parameter: Solar water pump, 72VDC, 62FT, 92GPM, 48 mm inlet/outlet diameter solar-powered pool pump, suitable for two 330W solar panels, 36V series installation. The pool pump in-ground is widely used in homes and industries, especially for saltwater. Notice: solar panel is not included. Customized specifications is available.
* Powerful Pump: Our swimming pool pump is equipped with a 900W pure stainless motor, rust-resistant, durable and powerful. It also features an impeller that maximizes flow, minimizes noise. The motor will not be overheated for the built-in heat-triggered protection when running, having a longer service life.
* Elaborate Details: There is a large filter barrel that is detachable for easy cleaning, and its transparent lid will give you a
clear view of the sewage inside the barrel. The highly sealed design prevents water leakage, ensuring the normal operation of pumping water. The pump gets energy from the sun through the solar panels, convenient and saving money.
* Plenty of Accessories: Our solar water pump is constructed with commercial-grade reinforced thermoplastic, sturdy and
corrosion-resistant, ensuring high strength and durability. Our pump also comes with a controller and some cables, which can connect the pump with a solar panel. There is a plastic wrench that can help you remove the filter lid, easy and convenient.
* Wide Applications: The solar pool pump is ideal for swimming pools, thermal springs, fishpond, and irrigation systems; you can choose it according to your different pumping water needs. It is almost no need to install it; convenient to use. It will be your perfect choice.
■ Technical description (related parts in contact with the liquid)
Pump head housing: Die casting aluminum alloys
Shield cavity: PPS+GF
Shaft sleeve: carborundum composite materials
Shaft: stainless steel(3CR14) shaft
Magnet housing: PPS plastic capsulation
Seal ring: EPDM
EMC: Grade 3
■ Driving device (Including motor)
Driving rotor: PPS plastic capsulated magnet
Screws and nuts: SUS 304 stainless steel
Driving Motor : brushless DC motor
Motor wire frame :PPA GF
Pump housing: Die-casting aluminum case with sandblasting and anodizing +PE powder coating..
Bracket hoop: US 304 stainless steel
Waterproof based on IP68 rating (en60529)
Connector model: 325304061AAH (matched Plug 325304061AMH)
Nozzle diameter:41mm (1.61 inch)
■ Mounting instruction
OWP-BL43-402CAN series pumps are centrifugal pumps which require pre-filled,
The pump installed in the lowest position of the system to ensure that the impeller is always immersed in the liquid, or pre-filled the pump before power on .
1: Pump should not be dry-running, even though it can dry-running for 15 minutes (after 15 minutes dry-running, it will automatically stop), Dry running will makes noise, also increasing abrasion to the shaft and shaft sleeve.
2:Use the recommended diameter pipe connecting the pump inlet, if you use a smaller diameter hose pump inlet, Due to the negative pressure in the pump, the outside air easier enter to the pump through the pipeline, it will make the pump performance degradation, and also the air bubbles make damage to the pump.
3: As viewed from the pump inlet direction, the impeller rotates clockwise (see the arrow on the outlet port).
4: The pump can be installed vertically or horizontally mounted (see figure 1 ) When installed vertically, the outlet port should be upward .
5:In order to avoid the dry- running (air get stuck in impeller),the water pump outlet port should be vertical or in the upper of the impeller. (see figure 1 )
6: The connected pipe should be vertically mounted (or no elbow in 20cm )to make the air discharged easily, the outlet pipe should not be used less than 90 degrees elbow (see figure 2).
7: Can't use the seawater or other heavy pollution with big grain impurity liquid as the liquid medium .
figure 1 figure 2
■ Temperature parameter
Medium liquid temperature: -40℃ to +85℃ (-40°F to + 185°F)
Working ambient temperature: -40℃ to +85℃ (-40°F to +185°F)
Storage temperature: -40℃ to +70℃ (-40°F to +158°F)
(up to 100 ℃, but it will shorten the service life)
■ System pressure
-0.2 to 2.5 bar ( 100℃ (212°F).
The service life is more than 20,000 hours based on the rated voltage and 36℃(86°F) ambient temperature.
■ Voltage range
Rated 24V water pump, workable range 18V - 32V
Although the motor can be used in a wide range of voltage and temperature, but excessive or too low voltage and temperature will affect the service life of the motor, the pump can not be exposed to thermal radiation ambient.
Medium liquid: liquid mixture (Water with below 60% glycol)
■ Electrical parameter
1. Working ambient temperature:-40℃--120℃, should try to avoid close to three-element catalytic, gas discharge pipe system and engine during the installation, ensure the working environment temperature.
2.The installation position of the water pump should as much as possible close to the low water level , to extend the service life of the pump.
4. Please use the pump far from the dusty environment, the dust is harmful to reduce the service life
5. Pay attention to the purity of the water, avoid to jam and impeller-blocked to reduce the service life of pump
